Optical System: Olympus UIS2 (universal infinity-corrected) optics for top tier performance

Illumination System: Built-in transmitted light, Köhler illumination with fixed field diaphragm technology,  pre-centered LED, power consumption is a low 2.4 W at 12 VDC

Focusing:  Stage height movement (coarse movement stroke: 15 mm )
Stroke per rotation for coarse adjustment knob: 36.8 mm, Focusing stopper
Torque adjustment for coarse adjustment knob
Fine focus knob (minimum adjustment gradations: 2.5 μm)

Revolving Nosepiece:   Fixed quintuple nosepiece with inward tilt

Stage:  Smooth wire drive movement mechanical fixed stage
(W × D): 211 mm × 154 mm
X-Y travel range: 76mm×52mm
Single specimen holder
(optional: double specimen holder, sheet holder)
Specimen position scale
Stage XY movement stopper

Observation Head:  Binocular head with trinocular port,
light path eyepiece/camera is 100-20/80 via prism slider.
Tube inclination 30°
Interpupillary distance adjusting range: 48-75mm
Anti-fungal treated

Eyepieces:  10x Field Number (FN) 20, w/rubber eyecups
15x Field Number (FN) 18, w/rubber eyecups optional

Condenser:  Abbe condenser NA 1.25 (oil immersion capable)
Universal multi-mode condenser with 7 rotating turret indent positions:
BF (4-100X), 2X, DF, Ph1, Ph2, Ph3, FL (Fluoresence)
8th non-indent position is a DF offset providing a 3D view.
Condenser turret aperture lock pin (BF only)
Built-in aperture iris diaphragm

Observing Methods: Brightfield, simple polarization, phase contrast, darkfield, 3D.

Objectives:
2X NA 0.05 W.D. 5.8mm*
4X NA 0.1 W.D. 18.5mm*
10X NA 0.25 W.D. 10.6mm*
10XPH NA 0.25 W.D. 10.6mm
20XPH NA 0.4 W.D. 1.2mm*
40XPH NA 0.65 W.D. 0.6mm*
100XOil PH NA 1.25 W.D. 0.15mm

*These are the 5 objectives included in our most popular system.

Voltage/current:  AC 100-240 V   50/60 Hz   0.4 A

Image Platform:           Sony Professional CMOS image chip
Chip Size:                       Approx 1/2″
Pixel Size:                      >3.7×3.7
Dark Sensitivity:           >1100mV
Output FPS:                   60 Frames per second at standard HDMI 1920×1080 (25FPS over WIFI)
Output 1:                       HDMI for direct HDTV connection (desktop/wallmount flat panels/projectors)
Output 2:                       USB; for on-board mouse control or WIFI transmitter output to computer
Image Capture:             JPEG format to on-board SD memory card or to computer
Video Capture:              ASF format 1080P 30fps to on-board SD memory card or to computer
Zoom Function:            High resolving digital zoom extends screen image magnification when needed
Internal software:         Screen toolbar for zoom, mirror, comparison, freeze, drawing, measurement
External software:        Full camera control, expanded menu, video/image capture, image manipulation
Operating system:        Microsoft® Windows® XP /Vista /7/8/8.1/10 (32 & 64 bit), OSx (Mac OS X), Linux
WIFI:                              Can be on or off as desired
Wireless Connect:         Maximum 3-6 connections dependent on environment and distance
Voltage/current:           Power supply DC 12V/2A

Microscope System Limited Warranty

Biomedx warrants that the microscope systems it sells and any related accessories bearing the Biomedx label (individually a “Product” and collectively the “Products”) will be free from defects in materials and workmanship under normal use and service for a period, beginning from the date of purchase, of ;

A) five (5) years for mechanical or optical defects and
B) one (1) year for electrical, or wear-related components.

Olympus microscopes through Olympus Life Science and Evident Scientific, of which Biomedx is an OEM/VAR (Original Equipment Manufacturer/ Value Added Reseller), applies similar terms.

For purposes of service for any defective Biomedx/Olympus microscope system, Biomedx should be the customers first point of contact for the problem. If any Product proves to be defective within the relevant warranty periods, the customer must return the defective Product to Biomedx with; 1) invoice showing date and place of purchase, 2) a detailed description of the problem.

Should service be needed, you will first need to contact Biomedx at the email address or phone number listed on this webpage in order to initially sort through the issue and if that issue is not able to be rectified on site, then to begin the process to return the defective item.

Biomedx (or Evident Scientific under its own terms where applicable), at its sole discretion, will repair, replace, or adjust the defective Product, provided that an investigation and factory inspection disclose that 1) such defect developed under normal and proper use and 2) the Product is covered under this limited warranty. Repair, replacement, or adjustment of defective Products shall be Biomedx sole obligation and the customer’s sole remedy hereunder. The customer is liable and shall pay for shipment of the products to Biomedx.

Biomedx shall not be obligated to perform preventive maintenance, installation, de-installation, relocation, or maintenance. Biomedx reserves the right to 1) use reconditioned, refurbished, and/or serviceable used parts that meet Biomedx quality assurance standards for repairs and 2) make an internal or external design and/or feature changes on or to its own Products without any liability to incorporate such changes on or to the Products.

Excluded from this limited warranty and not warranted by Biomedx in any fashion, either express, implied, or by statute, are:

products not manufactured or represented by Biomedx as OEM/VAR and/or not bearing the “BIOMEDX” brand label (the warranty coverage for products of other manufacturers, which may be distributed by Biomedx, is the responsibility of the manufacturers of such products in accordance with the terms and duration of such manufacturers warranties;
any Product which has been disassembled, repaired, tampered with, altered, changed, or modified by persons other than Biomedx own personnel unless repair by others is made with the written consent of Biomedx;
defects or damage to the Products resulting from wear, tear, misuse, negligence, sand, liquids, impact, cold, heat, light, humidity, fungus, other life form infestation, improper storage, non-performance of scheduled operator and maintenance items, or use of non-Biomedx brand accessories where required, consumables, or supplies; software programs; supplies and consumables.

Except for the limited warranty set forth above and for that which applies under terms of the direct Olympus/Evident warranty, Biomedx makes no and disclaims all other representations and warranties, whether express or implied, concerning the Products including but not limited to any implied warranties of merchantability or fitness for a particular purpose, or concerning any patents or technology used or included therein. If any implied warranties apply as a matter of law, they are limited in duration to the length of this limited warranty. All guarantees, warranties, conditions, and representations whatsoever, either express or implied, whether arising under any statute, law, commercial usage or otherwise, are hereby expressly excluded.

The customer acknowledges and agrees that Biomedx shall not be responsible for any damages that the customer may incur from delayed shipment, Product failure, Product design, selection, or production or from any other cause, whether liability is asserted in contract, tort, (including negligence and strict product liability) or otherwise. In no event shall Biomedx be liable for any indirect, incidental, consequential, or special damages of any kind (including without limitation loss of profits or loss of use), whether or not Biomedx shall be or should be aware of the possibility of such potential loss or damage.

Representations and warranties made by any person, including but not limited to dealers and representatives of Biomedx, which are inconsistent or in conflict with the terms of this limited warranty, shall not be binding upon Biomedx unless reduced to writing and approved by an expressly authorized manager of Biomedx.

This limited warranty is the complete and exclusive statement of warranty which Biomedx agrees to provide with respect to the products and it shall supersede all prior and contemporaneous oral or written agreements, understandings, proposals, and communications pertaining to the subject matter hereof.

This limited warranty is exclusively for the benefit of the original customer and cannot be transferred or assigned.

Special Warranty Terms for the
Biomedx MicroImagePro Camera

Sensitive electronic components can be subject to static electricity, heat, and power glitch issues. If a camera failure occurs within the first year of purchase, send it back and it will be replaced with a new camera (plus cost of shipping if outside the continental USA.) If failure occurs during year 2, a new camera replacement will be provided for $225 (plus shipping). Any camera failure beyond year 2 will be assessed on an individual basis for repair cost of parts and labor or cost of a unit replacement based on unit age and the current camera model in use.
